Short description
4-Channel Class-D Amplifier

Infinity Automotive

Primus 90041A

Model: INFPRIMUS90041AAM
UPC: 050036413022
Hearing is believing.

New
Please log in to see your price
About This Product

Description:

The Infinity Primus 90041A Amplifier is a High-Performance 4-Channel Class-D Amplifier engineered to accommodate a wide range of system configurations. With a suite of advanced features, it enables for precise tuning and optimization, delivering the ultimate listening experience. This compact amplifier is equipped with user controls including a bass EQ as well as HPF, LPF crossover controls for tailoring sound to suit the characteristics of your vehicles.


Great Performance at an Affordable Price

Compact Footprint

Full On-Board Protection

Start/Stop Compatible

Wide Input Sensitivity Range

Adjustable Bass EQ

OEM Load Detect Compatible

Crossover Controls

Immersive Sound Experience

Infinity Industrial Design

Max Power: 1480W peak

Power Output: 260Wrms x 2 @ Bridged 4 ohms full range

Power Output: 130Wrms x 4 @ 2 ohms full range

Power Output: 90Wrms x 4 @ 4 ohms full range

Frequency Response: 20Hz - 20kHz±1dB

THD+N@ROP: 1%

Input Sensitivity LOW: 0.2V - 5V, HIGH: 1V - 25V

High/Low Pass Filter, Variable: 32Hz - 320Hz

Bass EQ@45Hz: 0 - 12dB Variable

Protection: DCP, OVP, UVP, OCP, OTP

Operating Voltage: 9V - 16V

Fuse Rating: 30A x 2

Specifications
  • Enclosure Color
  • Black
  • Barcodes
  • UPC
  • 050036413022
